Details:
HIGH LEVEL TO RCA LINE STEREO CONVERTER
Advantages
- Converts a stereo amplified signal in two low-level line outputs for an amplifier.
- Eliminates noise interference – separated grounds
- Selectable DC and AC voltages detection – full compatibility with any original manufacturer head-units.
- Automatically generates a remote control signal to activate the associated amplifier
- Can be used in passive mode without 12V power supply (In that case the remote output doesn’t work)
Specifications:
| Bandwidth (+/- 1dB) | 10 Hz – 80 kHz |
|---|
| Signal/noise ratio | > 100dB |
|---|
| Distortion | < 0.01% |
|---|
| Automatic remote output | inferior to 0.01% |
|---|
| Stop & Start compatible | Automatic |
|---|
| DC detection threshold | 5.2V for 14.4 V input voltage |
|---|
| AC detection threshold | 22 mV @ 1 kHz |
|---|
